8000 Bottles / Hour Water Filling Machine

(0 reviews)

Get Price

(177) Views

(0) Contacts

1 set/sets

$11,500.00 - $49,800.00

Contact Company

Zhangjiagang Proman Machine Co.,ltd

Zhejiang, China

(910) Views

(1) Contacts

1. Using the wind-sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform does not need to adjust the equipment level, only change related to the curved plate, wheel, and nylon parts is enough.
3. The specially designed stainless steel bottle washing machine clip is solid and durable, with no touch with the screw location of the bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurately, and with no liquid loss.
5. Spiraling declines when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneider, and OMRON.

                                                            Model
                                                            CGF18-18-6

                                                            Main Motor Power
                                                            4.7kw

                                                            Capacity(500ML)
                                                            8000BPH

                                                            Weight
                                                            5500kg

                                                            Washing Heads
                                                            18

                                                            Suitable Cap
                                                            Plastic Screw Cap

                                                            Filling Heads
                                                            18

                                                            Height Of Bottle
                                                            150-310MM

                                                            Capping Heads
                                                            6

                                                            Diameter of bottle
                                                            Diameter: 55-110 MM

                                                            Suitable Bottle
                                                            PET Bottle ,Plastic Bottle
