KEC300 online conductivity/salinity analyzer is an online water quality analyzer developed on the basis of digital water quality analysis platform. Integrated design, using industrial on- line electrode, digital, intelligent analyzer design concept. The functions of electrode signal detection, temperature detection, automatic compensation and digital signal conversion are realized in the instrument. RS485 signal output, easy networking, and system integration, widely used in surface water, pollution sources and other industries.

                                                            Model number
                                                            KEC300

                                                            Contour dimension
                                                            205 mm × φ40 mm

                                                            Measurement parameter
                                                            Conductivity, salinity, temperature

                                                            Material Quality
                                                            Stainless steel, POM

                                                            Weight
                                                            0.5 kg

                                                            Method of measurement
                                                            Four wire graphite electrode method

                                                            Measurement mode
                                                            Immersion measurement

                                                            Power consumption
                                                            < 1W >

                                                            Measuring range
                                                            Conductivity: (0 ~ 500mS/cm), salinity: (0-100) ppt Temperature: (0 ~ 60) °C

                                                            Supply voltage
                                                            (12/24) V DC

                                                            Accuracy
                                                            ≤ ± 1%

                                                            Repeatability
                                                            ≤1%

                                                            Resolution
                                                            Conductivity: 0.01 s/cm, salinity: 0.01 PPT

                                                            Response time
                                                            ≤20s

                                                            Zero Drift (24h)
                                                            ≤ ± 1% F.S.

                                                            Range Drift (24h)
                                                            ≤ ± 1% F.S.

                                                            Accuracy of temperature compensation
                                                            ≤ ± 1%

                                                            Calibration period
                                                            Six months

                                                            Temperature range
                                                            (0 ~ 60) °C

                                                            Protection level
                                                            IP68

                                                            MTBF
                                                            ≥1440h/Time

                                                            Communication
                                                            RS485(Modbus RTU), maximum baud rate 115200 bps/ 4-20mA output

Surface water
Pollution sources
Other industries.

Characteristics of conductivity/salinity analyzer

RS485 connects with the Modbus RTU protocol
PH sensor is in the field of renewable
low-power supply
SS316 shells for a long lifetime.
Integrated design, anti-electromagnetic interference.
Industrial conductivity electrode, electrode constant stability, not affected by polarization, pollution.
Built-in temperature sensor, real-time temperature compensation Stainless steel case, IP68 waterproof grade, suitable for various working conditions.
RS485 signal output, Standard Modbus protocol, easy integration, networking.
