Installation Ⅰ
1. Tank depth H <3m
2. Direction can be adjusted in horizontal and vertical
3. Depth of the guide rod is 3 meters
Installation Ⅱ
1. When depth> 4m, need to add another side support on the guide rod.
2. The connection shall be an expansion bolt between the side support & tank wall, holder & tank bottom.
3. Please inform tank depth when you put the order to us.
Installation Ⅲ
1. When depth> 4m, need to add another side support on the guide rod.
2. The connection shall be an expansion bolt between the side support & tank wall, holder & tank bottom.
3. Please inform tank depth when you put the order to us.

                                                            PH
                                                            5~9

                                                            Liquid temperature
                                                            ≤ 40℃

                                                            Liquid density
                                                            ≤1150kg/m3

                                                            Max working depth
                                                            20m

                                                            Motor
                                                            IP 68 , 7/24 Continuous working

                                                            Motor
                                                            MUST diving in water while operating

Used for municipal sewage treatment plants and industrial wastewater treatment plants to produce low tangential flow with force
Used to create a flow for circulation, nitrification, denitrification, and phosphorus removal.

Compact structure, lightweight, easy to operate and maintain, simple installation
Self-cleaning blade, preventing debris from twining or blocking
Lowers energy consumption, high aeration rate preventing sedimentation
Two rows of independent mechanical seal, longer service life
Class F insulation of motor winding, motor protection grade IP68, imported permanent -lubricated maintenance-free bearings, chamber leakage detection, motor winding overheating protection
