Signal output: RS-485 (Modbus/RTU protocol).

Convenient connection to third-party equipment such as PLC, DCS, industrial control computer, general controller, paperless recording instrument, or touch screen. Immersion installation with 3/4 NPT pipe thread for easy submersible installation or installation in pipes and tanks. IP68 protection grade.

                                                            Model
                                                            DDM-406

                                                            Protection grade
                                                            IP68

                                                            Measuring range and resolution
                                                            0～20.00μS/cm  0.01  0～200.0μS/cm  0.1  0～5000μS/cm  1  0～200.0mS/cm  0.1

                                                            Power consumption
                                                            0.2W@12V

                                                            Precision
                                                            ±1.5%F.S.，±0.3℃

                                                            Working temperature
                                                            0～65℃

                                                            Working pressure
                                                            ＜0.6MPa

                                                            Power supply
                                                            12～24VDC ±10%

                                                            Signal output
                                                            RS-485(Modbus/RTU) and 4-20mA

                                                            Wetted material
                                                            ABS/SUS316L(Default）/PVC

                                                            Calibration
                                                            Two-point calibration

                                                            Mounting method
                                                            Immersion mounting, 3/4 NPT thread

                                                            Temperature compensation
                                                            Auto temperature compensation（Pt1000）

                                                            Cable length
                                                            5 meters, other lengths can be customized
