The CLI-206A integrated online chloride ion sensor USES an ion-selective electrode with a solid membrane for testing free chlorine ions in water, making it fast, simple, accurate, and economical. In this manual, the technical parameters, communication protocol, operation, and maintenance of the chloride ion sensor are introduced in detail.
Signal output: RS-485 bus, Modbus/RTU protocol, easy to connect to PLC, DCS, industrial control computer, general controller, paperless recording instrument or touch screen, and other third-party devices. The patented chloride ion electrode, with an internal reference fluid at a pressure of at least 100KPa (1Bar), slowly seeps out of the microporous salt bridge. The reference system is very stable and the electrode life is longer than that of ordinary industrial electrodes.
Easy to install: 3/4-inch NPT threads for submerged installation or installation in piping and tanks.
IP68 protection grade.

                                                            Model
                                                            CLI-206A

                                                            Protection grade
                                                            IP68

                                                            Measuring range and Resolution
                                                            0～3500mg/L   0.1mg/L   0～35000mg/L  1mg/L

                                                            Power consumption
                                                            0.2W@12V

                                                            Precision
                                                            ±5%，±0.5℃

                                                            Calibration
                                                            Two-point calibration

                                                            Working temperature
                                                            0～40℃

                                                            Cable length
                                                            5 meters, other lengths can be customized

                                                            Working pressure
                                                            ＜0.1MPa  pH range of the medium  2～12pH

                                                            Mounting method
                                                            Immersion mounting, 3/4 NPT thread

                                                            Temperature compensation
                                                            Automatic temperature compensation (Pt1000)

                                                            Material
                                                            POM

                                                            Power supply
                                                            12～24VDC

                                                            Signal output
                                                            RS-485 bus, Modbus/RTU protocol
